13201A, 23201A Plug & Play Accelerometer
Brand: American Sensor Technologies IncThe 13201A and 23201A accelerometers have either one or two orthogonal axes and a temperature sensor in a small, rugged package.
The small size and built-in power regulation allow them to fit in most applications without any external circuitry or conditioning. Suitable for dry gas and some fluids with Parylene or RTV protection (options). Non-standard excitation, compensated temperatures are available as options.
Each axial sensor has been tested over the -40° to 85° C temperature range. Each axis has a nominal full scale output swing of ±2 Volts from the zero-g output level of nominally +2.5 Volts. Precise values for each axis are provided on the calibration certificate included with each sensor.
Specifications
Accuracy
- ± 1.25 % of Full Scale Reading, Max.
Constant Acceleration
- ± 1 to ± 2 G
Electrical Connectors
- 3 x AWG 24
Enclosure, Body Material
- Aluminum - Anodized
Excitation Voltage
- 8.5-36 V
Frequency
- 0 to 2,100 Hz
Input
- 10 mA
Input Impedance
- 5 kΩ
Mounting
- Screw Mount
Operating Temperature
- -40° to 85° C (-40° to 185° F)
Output
- 0.55 - 4.8 V - Output Voltage Swing
Output Noise
- 110 to 200 µg/√Hz
Response Time
- 0.5 ms
Sensitivity
- ± 0.25 % - Transverse Sensitivity
- 1,000 mV/g
- 6.45 mV/°C
Shock
- ± 3,500 G - Shock Survival
Supply Voltage
- ± 80 V - Input Voltage
- 8.5-36 V - Input Voltage - Operating
Temperature Range
- -40° to 85° C (-40° to 185° F)
Vibration
- MIL-STD-704A
