R Series Pumps
Brand: Ampco PumpsR Series Self-Priming Pumps Are Corrosive Resistant.
For over 50 years the R Series self-priming marine industrial pump has been serving the shipping industry in fire and bilge pump applications.
This versatile pump is capable of self-priming up to 25ft/7.6m. The R Series features include temperature ratings as high as 225°F/ 105°C, multiple seal configurations and close-coupled options.
All R Series pumps are close-coupled to NEMA or IEC motors. The available corrosion resistant alloys include 316 stainless steel and nickel aluminum bronze.
All R Series pumps have ABS (American Bureau of Shipping) type approval and are available for delivery in only 1 week.
Fully shrouded impellers eliminate the need for frequent adjustments commonly required on most self-priming pumps.
Features- High Efficiency
- Multiple Alloys – 316 Stainless Steel, Nickel Aluminum Bronze
- Machined, Heavy Wall Construction
- NPT Fittings
- Multiple Commercial Seal Options – Type 21 Single Mechanical with Ceramic Seat, Standard.
- Temperatures up to 225°F (105°C)
- Pressure up to 175 psi (12 bar)
- Enclosed Impellers
- Closed-coupled to NEMA or IEC motor
- Advantages:
- Self-Priming up to 25 feet (7.6m)
- High Flow Rates
- Heavy Wall Cast Construction
- Versatility of Multiple Alloy Construction
- Flush and Frame Options Available
- One Week Delivery
- Manufactured and Assembled in the U.S.A.
Specifications
Brand
Model
- 5
Maximum Discharge Pressure
- 175 psi / 12 bar
Maximum Flow Rate
- 475 GPM /108 mᵌ/hr
Maximum Viscosity
- 1,200 cP
Seal Specifications
- 6 Seal Options
- Commercial Saltwater Applications
- Reverse Osmosis
- On-board Vessels
- Engine Cooling, Condenser Cooling, Refrigeration and Fire Pumps
- Effluent Wastewater, Brackish Water
