SCH-27 Pressure Switch
Brand: KOBOLD Instruments, IncThese diaphragm pressure switches are IP 65, and suitable for a variety of applications such as: food industry, cannery, pharmaceutical, petrochemical, conventional and nuclear power station, and they withstand the most unfavorable working conditions, caused by either the process fluid aggressiveness or high ambient temperature.
The sensing element is a metallic diaphragm and acts directly on the microswitch through a self-centering pivot. The simplicity of the design, without levers, cams or similar mechanism, gives the unit an exceptionally long working life.
Setting Range
Switch Type
Process Connection
Electrical Connection
Options
Pressure Option
Diaphragm
Mounting Bracket
Enclosure Material
Service
View Details
Part Number
SCH-27 F7 A l2 1 N
Specifications
Brand
Adjustment Type
- Internal, Micrometric Adjustable
Ambient Temperature Range
- -25° to 65° C (-13° to 149° F)
BSP Connection
- G 1/2" Male
Cover Material
- 304 Stainless Steel, Bayonet Lock
Diaphragm Material
- 316 Stainless Steel
- Carbon Steel Diaphragm Covered with AISI 316 Stainless Steel
- PTFE
Electrical Connectors
- 1 x External - Earth Contact
- 1 x Internal - Earth Contact
- M20 x 1.5
- Terminal Strip
Electrical Rating
- 0.1 A at 24 Vdc
- 15 A at 125 Vac
- 15 A at 250 Vac
- 20 A at 125 Vac
- 20 A at 250 Vac
- 6 A at 24 Vdc
Environmental Protection
- IP65 as Per IEC 529
Gasket Material
- PTFE
Materials of Construction
- AISI 304 Stainless Steel, etched - Tag
Mounting
- 2" Stake's Mounting Bracket
NPT Connection
- 1/2" 14 Female NPT
- 1/2" NPT Male
- 1/4" 18 Female NPT
- 1/4" NPT Male
Pressure Range
- psi: 58.0151 to 2320.6 (kPa: 400 to 16000, bar: 4 to 160) - Carbon Steel Diaphragm
- Up to psi: 36.2594 (kPa: 250, bar: 2.5) - AISI 316 Stainless Steel Diaphragm
Process Connection Material
- 316 Stainless Steel
Process Temperature
- 100° C (212° F) - Max.
Repeatability
- ≤ 1 %
Switch Type
- 1 to 2 SPDT Microswitches
- Adjustable Differential, Double
- Adjustable Differential, Single
- Gold-Plated & Insert Gas Filled, Double
- Gold-Plated & Insert Gas Filled, Single
- Gold-Plated, Double
- Gold-Plated, Single
- Inert Gas Filled, Double
- Inert Gas Filled, Single
- Insert Gas Filled Vdc, Double
- Insert Gas Filled Vdc, Single
- Standard, Double
- Standard, Single
System Pressure
- bar: 185
- kPa: 18,500
- psi: 2,683
Thermal Drift
- ≤ 0.05 %/°C (≤ 0.027 %/°F)
