Needle Valves, 15,000 psi - MAN Series
Brand: Parker HannifinParker's MAN Series MPI Needle Valves are engineered for use at pressures up to 15,000 PSI and temperatures as high as 600°F.
The heavy duty, bar stock design has a non-rotating lower stem that helps to extend packing life by removing stem rotation through the packing area.
Stem packing below the threads isolates the thread lubricant from the flow, ensuring adequate lubrication regardless of the media.
The MAN Series is available with MPI (Medium Pressure Inverted) ends to provide a secure tube grip on heavy wall instrumentation tubing.
This “ferrule style” design provides the installer with excellent application flexibility when designing a medium pressure tubing system.
Features- Non Rotating Lower Stem for longer valve life
- Packing below the threads
- Locking Device to secure valve body
- Powder Coated Handle
- Panel Mountable
Specifications
Brand
Body Material
- 316 Stainless Steel
Body Shape
- InLine, Three-Way, Two Pressure Connections, Three-Way, One Pressure Connection, Angle
Connection 1 Size
- 1/4" to 1"
Connection 1 Style
- MPI Compression Fitting, FNPT
Connection 2 Size
- 1/4" to 1"
Connection 2 Style
- MPI Compression Fitting, FNPT
Connection 3 Style
- N/A, MPI Compression Fitting
Connection 3 Thread Size (inch)
- 1/4" to 1"
Maximum Working Pressure (psi)
- 15000
Packing Material
- PTFE
Stem Type
- Blunt, Regulating
- Power
- Nuclear Plants
- Oil and Gas
- Chemical / Petro-Chemical
