3SD/4SD Series Simplex Control Panels
Brand: Goulds Water Technology3SD/4SD Series Simplex Panels provide simple, intuitive control where and when you need it most. Panels control 120/208/240V single phase or 208/240/480V three phase pumps and are designed for dewatering, wastewater, and sewage applications.
They come standard with a clear front NEMA 4X rated enclosure, IEC rated contactors, and a motor protective switch. All panels are UL listed for the United States and Canada and come standard with a five-year warranty.
Features- Indoor/outdoor NEMA 4X panel enclosure: heavy duty polycarbonate with stainless steel lockable latches
- Visible pump control indicators: pump hand-off-auto (H.O.A.) switch, green pump run lights, red pump fault lights with reset button, and power on light
- Visible alarm indicators: High red beacon alarm light, alarm test and silence buttons
- Alarm horn sounds at 85 decibels at 10 feet
- Remote monitoring by dry contacts: high liquid, pump run(s), and pump fault(s)
- Pump protection: motor protective switch (branch circuit protection, adjustable overload and disconnect) and thermal cutout with indicators
- Three floats with 50’ cords: stop, start, high level
- Sewage pump chambers
- Grinder pumps
- Sump pump basins
- Lift stations
