AST Industrial Pressure Transducer, MSP100

MSP100 Industrial Pressure Transducer

Brand: American Sensor Technologies Inc
Add Product to My Catalog

The MSP100 pressure transducer provides stainless steel media compatibility in a low cost, small profile solution.

This sensor has no silicone gel or polymeric media isolation methods to fail in contact with water or other harsh chemicals. Pressure connections are provided via an O-ring seal. The device is available in both Analog and 14-bit digital output with a port material of either 316L Stainless Steel or 174PH. Additional custom port options available to meet your application needs. The small size vs. performance and media compatibility are provided through solid-state technology.
Features
  • Single Piece Construction; No Welds, No Oil
  • 100% Stainless Steel Isolation for Harsh Chemical Measurement
  • Low Cost
  • 14-Bit Digital Output or Analog

Specifications

Brand

Accuracy

  • ± 0.2 % of Span
  • ± 0.5 % of Span

Ambient Temperature Range

  • 25° C (77° F)

Compensated Temperature

  • 0° to 45° C (32° to 113° F)

Consumption

  • 2 mA
  • 3 mA

Electrical Connectors

  • 2 ft (0.6 m)

Enclosure, Body Material

  • 316L Stainless Steel
  • 630 Stainless Steel

Insulation Resistance

  • 50 MΩ at 250 Vdc

Operating Temperature

  • 0° to 55° C (32° to 131° F) at 250 Vdc

Output

  • 0.5 - 5 V
  • 0.5 V
  • 4.5 V
  • 80 to 100 mV

Pressure Range

  • bar: 0 to 34.47
  • kPa: 0 to 3,447
  • psi: 0 to 500

Pressure Type

  • Gauge

Resolution

  • 14-bits

Response Time

  • 0.1 ms
  • 3 ms at 4 MHz
  • 8.4 ms at 4 MHz

Shock

  • 50 G, 11 ms Half Sine Shock per Mil Standard 202F

Span & Zero Effect

  • ± 2 % of Span

Stability

  • 0.25 % of Span

Supply Voltage

  • 2.7 - 5 Vdc (Digital, Output Signal "J" or "S")
  • 3 V
  • 4.75 - 5.25 Vdc (Analog, Output Signal "2")
  • 5 V
  • 5 Vdc - Typical

Vibration

  • ± 20 G MIL-STD-810C, Procedure 514.2

Zero Offset

  • ± 2 mV Ratiometric

  • Beverage Dispensing Systems
  • Water Pressure or Flow Monitor
  • Medical Equipment
  • Industrial Equipment/Hydraulics
  • Tank Level Measurement
  • Manifold Pressure

Documentation

Data Sheets
