Electronic Proportional Regulators - P3YP Series
Brand: Parker HannifinP3YP high flow programmable electronic proportional regulator allows for regulation of outlet pressure proportionally to an electrical control signal. The control signal and version options must be ordered discretely in the part ordering code.
P3YP preset electronic proportional regulator is comprised of a piston operated pneumatic pressure regulator controlled by a closed loop system in order to deliver best performance and reliability.
It allows for regulation of outlet pressure proportionally to an electrical control signal. This unit is factory set and must be ordered by customer specification with either 0-10V, 0-20mA, or 4-20mA control signal.
Normally closed (NC) or forced exhaust normally open (NO) versions. Units can be ordered in normally closed (NC) or forced exhaust normally open (NO) versions.
For the forced exhaust version, when supply voltage is lost, the unit will automatically exhaust the regulated pressure to zero.
Internal miniature valves control the output pressure proportionally to a field convertible analogue input control signal of 0-10V, 0-20mA or 4-20mA.
Features- Integral 3/4" or 1" ports (BSPP & NPT)
- Accurate output pressure
- Very fast response times
- Robust but lightweight design
Specifications
Brand
Configuration Type
- Fixed
Control Method
- 0-10 V, 4-20 mA
Display
- N/A
Electrical Connectors
- 8-Pin M12 & 5-Pin M12
Environmental Rating
- IP65
Inlet Pressure Range (bar)
- 0 to 21
Inlet Pressure Range (psig)
- 0 to 305
Input Supply Voltage
- 24 Vdc
Maximum Flow Rate (m³/hr)
- 150
Maximum Flow Rate (scfm)
- 88
Media
- 40 μ Filtered Compressed Air / Inert Gas
Port Size
- 1/2"
Port Type
- BSPP
Power Consumption (W)
- 6
Pressure Control Range (bar)
- bar: 0 to 20
Pressure Control Range (psig)
- psig: 0 to 290
Product Type
- Electronic Proportional Regulator (Pulse Width Modulated)
Response Time (msec)
- Filling: 120 / Emptying: 190
Temperature Range (°C)
- 0° to 50° C
Temperature Range (°F)
- 32° to 122°
Weight (kg)
- N/A
Weight (Lbs)
- N/A
- Welding applications
- Material handling
- Pick and place
- Flow regulation
- Pressure regulation
- Positioning
