Medical Scroll Air Compressor
Brand: GlobalVac & AirGVA’s medical scroll air compressors feature completely oil-less technology, ensuring 100% oil-free air delivery. With minimal moving parts, they require less maintenance and offer a longer operating life. Additionally, their energy-efficient design provides more airflow while consuming less power, making them a reliable and cost-effective solution for various applications.
The NFPA PLC control panel includes:
- Dual 120V Control Transformer with CB Protected Primary/Secondary Circuits
- PLC Touch Screen & Keypad integrated with HMI
- H/O/A Switch, Run Light, and Hour Meter integrated into PLC
- Dual 120Vac/24vdc Power Supply
- UL 508 Listed/NEMA 12 Enclosure
- Finger Safe Power Distribution Block
- Auto Restart after Power Outage
- Door Mounted Disconnect
- System Fault Indicator display on PLC
- System Parameters selection via PLC
- Door Mounted Motor Circuit Protector for Each Pump
- PLC By-pass allows Pump Operation with MCPs
- Dry Contacts for Remote Monitoring
- Full Voltage Motor Starter for Each Pump
- Single-point connections for process air, electrical, and condensate drainage make installation straightforward.
- ASME-certified receivers come standard with a corrosion-resistant epoxy lining.
- Intuitive touchscreen controls will give you all the information you need for the system operation, service requirements, alarms, and more.
- Integrated aftercoolers and water separators ensure bulk liquid removal and appropriate air temperatures for optimized dryer functionality.
- Multi-skid systems with quick connections between each skid ensure each skid will fit through a standard doorway and make installation straightforward.
- Remote monitoring, BMS communication, & ethernet connectivity allow you to monitor your system in the way that best suits your needs.
