Ultra-High Purity (UHP) Two-Stage, Tied Diaphragm Pressure Regulator - 735W & NPR735W Series
Brand: Parker Hannifin735W Series Two-stage Pressure Regulators are designed for high-pressure UHP applications.
The series provides excellent reliability and low supply pressure effect -- ensuring stable outlet pressure regardless of inlet pressure fluctuations.
Specifications
Brand
Body Material
- 316L Stainless Steel
Burst Pressure
- 10,500 psig (724 barg)
Cap Material
- Nickel-Plated Brass
Compression Member Material
- 316L Stainless Steel Standard, Hastelloy C-22
Diaphragm Material
- 316L Stainless Steel Standard, Hastelloy C-22
External Leak Rate
- < 2 x 10-10 Scc/sec He
Flow Capacity (Cv)
- Cv 0.04
Internal Leak Rate
- < 2 x 10-9 Scc/sec He
Internal Volume (cc)
- 10. 10 cc without Fittings
Knob Material
- ABS
Maximum Inlet Pressure (barg)
- 240 barg
Maximum Inlet Pressure (psig)
- 3500
Maximum Working Temperature (°C)
- 65° C
Maximum Working Temperature (°F)
- 150° F
Minimum Working Temperature (°C)
- -40° C
Minimum Working Temperature (°F)
- -40° F
Nut Material
- 316L Stainless Steel
Outlet Pressure
- 1-30 psig (2 barg) 3-100 psig (7 barg) (735W) -25 inHg to 30 psig (NPR735W)
Poppet Material
- 316L Stainless Steel Standard, Hastelloy C-22
Poppet Screen Material
- Hastelloy C-22
Poppet Spring Material
- 316L Stainless Steel Standard, Inconel
Proof Pressure
- 5,250 psig (362 barg)
Seat Material
- PCTFE (Standard), Vespel
Weight (kg)
- 1.6
Weight (Lbs)
- 3.5
